Medea

Medea
Will bring fantasy to life





With 4K UHD resolution, 6,500 lumens of laser illumination and custom Barco Pulse electronics, Medea has been optimized to deliver unprecedented fun in small to medium-sized media rooms.

Professional grade optics

Medea’s optical engine architecture is nothing but world-class. It is built from custom designed aspherical glass elements and enhanced low dispersion glass lenses. The resulting image quality is simply outstanding.

State of the art electronics

All new “Pulse” electronics are built on a superior FPGA platform featuring a dual core processor on the industry’s only 20 nm SoC, with 96 transceiver lanes delivering 3.3 Tbps of serial bandwidth. It has been designed to process 4K with HDMI 2.0a and HDCP 2.2 and HDR10 with extremely low latency, thanks to our unique single step processing technology. Barco’s RealColor processing enables simple and accurate calibration to any desired white point or greyscale.

Award-winning DLP technology

Medea utilises the very latest 0.66" diagonal Micromirror Array from TI, it displays 4K Ultra High Definition (UHD) 3,840 × 2,160 pixels on screen, features a 5.4 Micron Micromirror Pitch and a ±17° Micromirror Tilt (Relative to Flat Surface).

Laser light source

Medea is packed with a brand new laser engine. Alongside significantly improved image uniformity, lasers last longer than traditional projector lamps, are not as fragile and offer nearly instant on/off. Light output is up to 6,500 ANSI lumens.



Technology: 0.66" Three-Chip DMD™

Resolution: 3,840 x 2,160 px @ 60Hz

Light Engine: Laser phosphor

Light source lifetime: Up to 40.000 hours

Light output: up to 12,00 lumens in DCI/P3 mode

Contrast: 1300 :1 (350:1 ANSI)

Lenses:

GLD 0,80 - 1.00 : 1
GLD 1.00 - 1.35 : 1
GLD 1.35 - 2.00 : 1
GLD 2.00 - 3.00 : 1
0.57 : 1 (UST Lens) With an adapter
0.86 : 1 (EN47) with an adapter
1.06 - 1.60 : 1 (EN66) with an adapter
1.58 - 2.25:1 (EN 63) with an adapter
2.25 - 3.31 : 1 (EN61) with an adapter
3.3 - 6.08 : 1 (EN 44) with an adapter

Lens shift range:

Varies depending on lens.

Inputs:

HDBaseT, HDMI 2.0, DVI, DisplayPort, SDI, DMX

Control drivers: Control4, Crestron, RTI and Savant

3D: 3D Capable (framepacked)



Control:

Remote, keypad, RS232, Network


Power requirements:

100 - 240 V / 50-60 Hz

Power consumption:

850 W Max

Noise level (typical at 25°C/77°F): 35 dB(A) (max)

Operating temperature: 10 to 45 °C (sea level)

Operational humidity: 20 to 80% (relative humidity)

BTU per hour: Max 2900 BTU/h

Installation: Free rotation

Dimensions:

(WxLxH) 540 x 725 x 3555 mm (excluding lens)
28.54 x 21.26 x 14 in. (Inc Feet/ excluding lens)

Weight: 48kg / 105lbs (excluding lens)

Shipping Dimensions:

850 x 665 x 613 mm (excluding lens - packaged separately)
33.46 x 26.18 x 24.13 in. (excluding lens - packaged separately)

Storage temperature: 0 to 40 °C

Warranty: Limited 3 years parts and labor
Extendable up to 5 years

* Firmware upgradable
